This product is a high-performance composite component manufactured using fluorosilicone (FVMQ) overmolding on PA+GF (Glass Fiber Reinforced Nylon).
It combines the high mechanical strength and dimensional stability of PA+GF with the excellent chemical resistance and elasticity of fluorosilicone rubber, making it suitable for demanding industrial, automotive, and fluid system applications.
The overmolding process forms a durable interface between the rigid structural substrate and the flexible sealing layer, enabling both load-bearing capability and reliable sealing performance in harsh environments.
Key Advantages of Fluorosilicone Over PA+GF
Excellent Chemical and Fuel Resistance
Fluorosilicone provides superior resistance to aggressive media compared to standard elastomers.
- Resistant to fuels such as gasoline, diesel, and aviation kerosene
- Excellent resistance to oils, hydraulic fluids, and lubricants
- Stable performance in chemical exposure environments
High Strength PA+GF Structural Base
PA+GF (glass fiber reinforced nylon) provides excellent mechanical properties.
- High stiffness and load-bearing capacity
- Excellent dimensional stability under stress
- Good wear and fatigue resistance
Wide Temperature Resistance
The combined material system ensures stable operation under extreme conditions.
- Operating temperature: -40°C to 200°C
- Maintains mechanical integrity at elevated temperatures
- Suitable for thermal cycling environments
Reliable Integrated Sealing Structure
Fluorosilicone overmolding eliminates the need for separate sealing components.
- No O-rings or secondary assembly required
- Reduced leakage risk under vibration and pressure
- Long-term sealing stability
Strong Adhesion Between Elastomer and Composite Substrate
Special surface treatment and molding processes ensure reliable bonding.
- Improved interfacial adhesion
- Resistance to delamination under stress
- Suitable for dynamic and high-load applications
Manufacturing Process
The product is manufactured using precision overmolding technology:
- PA+GF Injection Molding
Glass fiber reinforced nylon is molded into the structural base. - Surface Preparation
Cleaning and activation improve bonding performance. - Fluorosilicone Overmolding
FVMQ material is injected onto the PA+GF substrate. - Thermal Curing
Elastomer is cured to form a stable bonded interface. - Quality Inspection
Sealing performance, adhesion strength, and dimensional accuracy are tested.
Technical Specifications
| Item | Description |
|---|---|
| Product Name | Fluorosilicone Overmolded PA+GF Component |
| Base Material | PA+GF (Glass Fiber Reinforced Nylon) |
| Overmold Material | Fluorosilicone Rubber (FVMQ) |
| Process | Injection Overmolding |
| Temperature Range | -40°C to 200°C |
| Chemical Resistance | Fuels, oils, hydraulic fluids, solvents |
| Mechanical Strength | High (fiber reinforced structure) |
| Structure Type | Rigid + flexible integrated component |
| Application Type | Sealing + structural support |
Applications
- Automotive fuel system components
- Engine compartment sealing parts
- Industrial hydraulic system components
- Oil and gas equipment parts
- High-load mechanical sealing structures
- Precision fluid control systems
- Chemical-resistant industrial assemblies
Engineering Considerations
Adhesion Between PA+GF and Fluorosilicone
Glass fiber reinforced nylon has a low surface energy, requiring:
- Plasma or chemical surface treatment
- Specialized primer systems
- Mechanical interlocking design features
Material Compatibility Optimization
Fluorosilicone is selected for environments where standard silicone fails, especially:
- Fuel exposure systems
- Hydraulic oil environments
- High temperature and chemical stress conditions
Structural Reinforcement Design
PA+GF provides:
- High stiffness under load
- Improved creep resistance
- Long-term dimensional stability
Frequently Asked Questions
Why use fluorosilicone instead of standard silicone?
Fluorosilicone provides significantly better resistance to fuels, oils, and aggressive chemicals.
What is the advantage of PA+GF material?
PA+GF offers high strength, rigidity, and excellent dimensional stability for structural components.
Can this part be used in fuel systems?
Yes, it is suitable for automotive and industrial fuel system applications.
Is customization available?
Yes, geometry, fiber content, fluorosilicone hardness, and sealing structure can be customized.
